Cisco, 8x GE PoE+, 2x GE SFP, Network Essentials, new
The Cisco Catalyst IE3300 IE-3300-8P2S-E is a rugged, fanless DIN rail switch with eight Gigabit Ethernet RJ-45 ports with PoE and PoE+ and two Gigabit SFP uplinks, running Cisco IOS XE with the Network Essentials feature set. It is built for factories, utilities, transport and outdoor cabinets that need managed Gigabit switching in harsh conditions, and for powering cameras, access points and sensors at the edge.
USD 6,031per unit, excl. VAT and duties
10 plus available
The IE3300 is Cisco's modular industrial Gigabit switch. The IE-3300-8P2S-E base unit has eight 10/100/1000 copper ports with PoE and PoE+, two 100/1000 SFP ports for fibre uplinks, dual redundant DC power inputs and alarm contacts. A single IEM-3300 expansion module adds copper, PoE, SFP or 2.5G ports, taking the system to as many as 26 Gigabit ports. It is fanless and convection cooled, rated from -40°C, and certified for industrial automation, substations (IEC 61850-3, IEEE 1613), rail and hazardous locations (Class I Div 2, ATEX Zone 2) when installed in a cabinet.
It runs Cisco IOS XE with secure boot, image signing and the Cisco Trust Anchor module, and supports industrial protocols including CIP EtherNet/IP, PROFINET, IEEE 1588 PTP v2 and ring resilience with REP and MRP. It can be managed through the WebUI, Cisco Catalyst Center or NETCONF and RESTCONF, and hosts IOx applications such as Cisco Cyber Vision.
The -E suffix means the switch ships with the perpetual Network Essentials licence: Layer 2 switching, static and inter-VLAN routing, security, QoS and industrial features. Network Advantage, available on the -A models or as the IE3300-NW-A= upgrade, adds dynamic routing (OSPF, BGP, EIGRP, IS-IS), VRF-lite, PIM multicast routing and MACsec-256. Catalyst Center Essentials and Advantage are optional add-on subscriptions. The PoE budget depends on the DIN rail power supply: 54 VDC is required for PoE+, and the total switch and PoE load must stay within the supply rating.
| Downlinks | 8x 10/100/1000 PoE/PoE+ RJ-45 |
|---|---|
| Uplinks | 2x 100/1000 SFP |
| Expansion | One IEM-3300 expansion module, up to 26 Gigabit Ethernet ports in total |
| PoE budget | 240 W base, 360 W with a PoE expansion module |
|---|---|
| Power inputs | Dual redundant DC, 9.6 to 60 VDC; 48 VDC needed for PoE, 54 VDC for PoE+ |
| Power consumption | 32 W, excluding PoE |
| Maximum input current | 10.5 A |
| Forwarding rate | Line rate on all ports and packet sizes |
|---|---|
| MAC addresses | 16K |
| VLANs | 256 |
| Memory | 4 GB DRAM, 1.5 GB user flash |
|---|---|
| Software | Cisco IOS XE, Network Essentials |
| Console | RS-232 (RJ-45) and USB mini Type B |
| Alarms | 2 alarm inputs, 1 alarm output |
| Dimensions (H x W x D) | 15.2 x 9.1 x 13.5 cm (6 x 3.6 x 5.3 in) |
|---|---|
| Weight | 1.7 kg (3.8 lb) |
| Mounting and cooling | DIN rail, fanless convection cooling, IP30 |
| Operating temperature | -40 to +70°C in a vented enclosure; up to +75°C with 200 LFM forced air |
|---|
| MTBF | 611,350 hours |
|---|
Source: manufacturer documentation, checked 22 October 2026. Tensor figures follow NVIDIA's stated basis; sparse figures are marked.
IE-3300-8P2S-E has PoE/PoE+ on all eight copper ports; IE-3300-8T2S-E has the same ports without PoE and draws less power. The -A versions add the Network Advantage feature set. IE-3300-8T2X and IE-3300-8U2X models replace the Gigabit SFP uplinks with two 10G SFP+ ports.
